MG II Series COB
MG015-II COB
모델:
MG015-II COB
MG015-II COB는 1.56mm 픽셀 피치를 적용한 COB Indoor Fine Pitch LED Display로, 선명한 화질과 안정적인 운영 성능을 균형 있게 제공하는 실내용 LED 디스플레이입니다. Full Flip Chip COB, 30,000:1 명암비, 3,840Hz 고주사율, 전면 유지보수 구조를 갖춰 기업, 공공, 상업 공간의 대형 영상월 구축에 적합합니다.
핵심 기능
- Available in 1.25, 1.56mm pixel pitch
- Front/rear installation and front access
- 16:9 cabinet in 600x337.5x40, cabinet is 4.5KG only
- Micro LED full flip-chip, high EO efficiency, reliability
- COB module, IP65
- Real and virtual pixel available
- Modules without bracket, attached to cabinet frame directly
구매 / 프로젝트 문의
구매, 설치 상담, 제품 문의는
전문 상담을 통해 안내해 드립니다.
Tech Spec
LED 세부 스펙
- Pixel Structure
- Full Flip Chip COB
- Pixel Pitch
- 1.56mm
- Module Resolution
- 192 × 108 dots
- Module Size
- 300 × 168.75mm
- Module Weight
- -
- Cabinet Module Composition
- 2 × 2
- Cabinet Resolution
- 384 × 216 dots
- Cabinet Size
- 600 × 337.5 × 39.9mm
- Cabinet Area
- 0.2025㎡
- Weight
- 4.3kg / cabinet, 21.5kg/㎡
- Pixel Density
- 409,600 point/㎡
- Brightness
- 600nit
- Scanning Method
- -
- Color Temperature
- 3,000~10,000K Adjustable
- Viewing Angle
- Horizontal 170° / Vertical 150°
- Brightness Uniformity
- -
- Color Uniformity
- -
- Contrast Ratio
- 30,000:1
- Power Consumption
- Max 257W/㎡
Average 68W/㎡ - Power Supply Requirements
- AC100~240V
- Frame Rate
- 60Hz
- Refresh Rate
- 3,840Hz
- Typical Life
- 100,000 hours
- Operating Temperature
- -10~40℃
- Storage Temperature
- -20~60℃
- Operating Humidity
- 10~80% RH, no condensation
- Storage Humidity
- 10~85% RH, no condensation
- IP Rating
- IP65 module front side
- Maintenance
- Front module maintenance / Front PSU & others maintenance
